Product Details
- Size: 110MM
- Place of Origin: China
- Brand Name: HD RECEIVER
- Model Number: 110mm
- Weight: 0.500 kg
Fully DVB-T/T2 compliant
Easy and fast software upgrade through
Support Auto/NTSC/PAL
4:3&16:9wide screen
Parental lock function
8 Favorite channel groups
Subtitle and Teletext support
Seven days EPG
Support USB PVR function
Support Time-shift function
Coaxial or Optical S/PDIF output
Software Upgrade through USB port and download from air
FormatFAT16/32and NTFS file system
Support Native Game
- Size: 110MM
- Place of Origin: China
- Brand Name: HD RECEIVER
- Model Number: 110mm
- Weight: 0.500 kg
| FEATURE LIST | |
| CHIPSET: MSD7T01 | * Dolby AC-3 optional |
| * Fully comply with DVB-T and DVB-T2 Standard | * HDMI 1080Poutput |
| * Supporting H.264, DIVX, MP3, MKV, MP4,JPEG, AVI etc. | * Supports updating software by USB 2.0 |
| * USB 2.0, Media player for DIVX,AVI, MKV, MP3, MP4,H.264, JPEG etc.. | * 7 days EPG |
| * PVR, Schedule recording | * Banner-- time & transparancy control abillity |
| * Multi-language OSD | * Display of signal strongness & quality |
| * Local language MENU | * CVBS,Coaxial,HDMI |
| * H264(MPEG 4) & MPEG-2 decoding | * Preview of TV channel |
| * Resolution at 576I/P, 720I/P, 1080I，1080P | * Full function Remote Controller. |
| * Output: PAL, NTSC | * 4-digit LED indicates channel number and time (optional) |
| * Automatic or manual Area serching | * Powerful channel editor functions |
| * 4：3PS、4：3LB、16：9 | * time shift function (Optional) |
| DETAIL SPECIFICATION | |
| CHIPSET: MSD7T01 | * Dolby AC-3 optional |
| * Fully comply with DVB-T and DVB-T2 Standard | * HDMI 1080Poutput |
| * Supporting H.264, DIVX, MP3, MKV, MP4,JPEG, AVI etc. | * Supports updating software by USB 2.0 |
| * USB 2.0, Media player for DIVX,AVI, MKV, MP3, MP4,H.264, JPEG etc.. | * 7 days EPG |
| * PVR, Schedule recording | * Banner-- time & transparancy control abillity |
| * Multi-language OSD | * Display of signal strongness & quality |
| * Local language MENU | * CVBS,Coaxial,HDMI |
| * H264(MPEG 4) & MPEG-2 decoding | * Preview of TV channel |
| * Resolution at 576I/P, 720I/P, 1080I，1080P | * Full function Remote Controller. |
| * Output: PAL, NTSC | * 4-digit LED indicates channel number and time (optional) |
| * Automatic or manual Area serching | * Powerful channel editor functions |
| * 4：3PS、4：3LB、16：9 | * time shift function (Optional) |
| DETAIL SPECIFICATION | |
| Main system | Audio/video data in/out |
| CPU:MSD-7T01 | Audio output:HDMI 1.3 SCART, coaxial |
| Tuner:MXL608 | Video output:HDMI 1.3, SCART |
| Tuner & Demodulator | Power supply |
| ANT. Connector:IEC TYPE, female | Input voltage：AC90--240V, 50/60Hz |
| Loop Outpur:IEC TYPE, male | Type：AC Power |
| Input Frange range:177.5~226.5MHz 474~858MHz | Consumption：Max. 10 w |
| Input Impedance:75 Ω | Protection:Separate fuse & chassis ground |
| Input Signal level:78 dBm to -20 dBm (average power) | or electric shock protection |
| Mpeg Audio/ Vedio Decocding | Operation Enviroment: |
| Video:MPEG 2(ISO/IEC 13818-2)/MPEG-4 (ISO/IEC14496-2)/H.264 (ISO/IEC14496-10) 1080P@30 fps | Operation tempreture : 5℃～55℃ |
| Profile Level :MPEG-2MP@ML(up to 1080p@30fps)/MPEG-4 ASP@L5HD(up to 1080p@30fps) | Storage tempreture:-40℃～ 65℃ |
| Input rate :Max. 60M bits | |
| Aspect ratio:4:3, 16:9, letter box | |
| Video Resolution:720*576i | |
| Audio decoding:MPEG-1 Layer I/II, MPEG-2 layer I/II, /;AAC, AAC /HE-AAC/AC3/E-AC-3/DTS | Dimension |
| Audio mode:Mono/Joint Stereo/Stereo | Size (W*D*H):130*80*33mm |
| Sample rate:32, 44.1 & 48 MHz | Weight: 0.30KG |
| Remark: | |
| 1. CE and ROHS certificate can be offered before shipping. | |
| 2.The front panel can be changed to same size | |
| 3. Sample charge:unit price plus its 30%,sample charge will be returned after order is confrimed. | |
